Gerni MH 4M 190/960 3 phase Electrical Hot Water Pressure Washer Choose MH 4M 200/960X
Replaced By The Gerni MH 4M 200/960X
The MH 4M 190/960 series continues to deliver high performance, ease of use, low noise and high cleaning efficiency. Factsheet HERE
QuickService concept give low running and maintenance costs, robustness, durability and high cleaning efficiency.
Heating costs are reduced with the award winning diesel powered EcoPower boiler ( > 92% efficiency). Sound level is reduced thanks to the 1450 rpm motor.
Features:
*3 Phase Electrical Power * 2,750 PSI Max Water Pressure
* Full ceramic piston pump.
* Easy to use control panel: all controls in one place.
* Ergo accessory system for additional user comfort.
Specifications:
* CABLE LENGTH; 5 meters * POWER; 6.9 kWatts * CURRENT; 12.5 Amps.
* SUPPLY VOLTAGE 415V Three Phase. * SUPPLY FREQUENCY; 50 Hz.
* WATER FLOW QMAX/QIEC; 950/900 Litres Per Hr.
* WATER TEMPERATURE (Water/Steam); 80/140C
* PUMP: 1450 RPM 190 Bar/ 2750 PSI
* FUEL: Diesel. * FUEL CONSUMPTION; 4.4 kg/Hr.* FUEL TANK CAPACITY; 15 lits.
* DETERGENT TANK CAPACITY; 10 litres.
* HIGH PRESSURE HOSE; 15 Meters DN8 on Hose Reel. * NOZZLE SIZE; 0500
* MASS; 136.5 kg * DIMENSIONS; 1053 mm L x 685 mm W x 760 mm H.
* STANDARD ACCESSORIES; Ergo 2000 gun, Tornado lance and Tornado Plus nozzle 0500.
OPERATING INSTRUCTIONS
- Don't use turbo lance above 80 degrees (Opposite the off position on the main switch).
- Don't use a surface cleaner above 60 degrees
- Check the fuel level before use.
- Check the detergent container is full, and the dial turned off.
- Pre-select the desired temperature.
- If the steam is to be used, set the temperature to maximum and back off the steam dial which is found next to the pressure guage two turns anti-clockwise.
- Then switch on the unit.
IMPORTANT
WHEN HOT WATER / STEAM HAS BEEN USED AND UNIT IS NOT BEING USED FOR AT LEAST 10 MINUTES, TURN THE TEMPERATURE DIALS DOWN AND FLUSH UNIT THROUGH WITH COLD WATER UNTIL THE LANCE IS COLD.
Hot water units should only be used for a maximum of 2 hour at a time before resting for at least one hour, with power and water supplies turned off.
